Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



FEATURES

• ConvertsTimeCodestoparallelBCD

• ReadsSMPTE(EBU,film&non‐dropframes)

• ReadsIRIG‐B

• OutputsparallelBCDtimeinformation

• Outputformatisdirectlycompatiblewith

UtahScientificMC‐500seriesswitchers

• 120/240VACwithsuppliedexternalwallmounted

powersupplyor

• 12VDCoperation

• Powersuppliesavailableformostcountries





SPECIFICATIONS

I/OConnections

• Inputpoweris12VDCvia2.1mmmalepower

connector

• TimeCodeinput:BNCsocket

• BCDoutput:db‐25



OperatingParameters

• Temperature:0to+70°C

• Humidity:Upto90%(non‐condensing)

• StorageTemperatures:‐40°to+70°C



Physical

Size:

4.2wx1.5hx5.5din

Weight:

16oz

10.6wx3.8hx14dcm 435g



 

Case

• Cover:Off‐whitealuminum

• Front/rearpanel:Clearanodizedaluminum

• Optionalrackmountkitisavailable─

RM4(seeabove)



Time Code Interfac

TCC 100P

Rack mountable with an RM4
