FEATURES

• ReadsSMPTEandEBUTimeCodes

• ‐11to+12hourselectableTimeZoneoffsets

• AutomaticDaylightSavingsTimeadjustments

(selectable)

• TimeanddateinformationviaRS‐232

orRS‐422

• Timemarkpulseoutput(ttllevel)at

1per:second,minute,hourorday

• Drycontactclosureat1per:

minute,hourorday

• Contactandpulseoutputcanbeadvanced

by1secondforsystemre‐syncat

59secondpoint

• HeathkitWWVclockoutputemulation

(forGVswitchers)

• OutputTimeCodeasspecif ied withabove

options



SPECIFICATIONS

I/OConnections

• TimeCodeinput:BNCsocket

• RS‐232,pulse,contactclosureand

TimeCodeoutput:DB‐9male

• OptionalDB‐9toBNCadapter:BNC‐9

• Inputpoweris12VDCvia2.1mmmalepower

connectorconvertedfromwallmount115/230

VAC,50/60Hz



OperatingParameters

• Temperature:0to+70°C

• Humidity:Upto90%,non‐condensing







Physical

Size:

4.2wx1.5hx5.5din

Weight:

16oz

10.6wx3.8hx14cm 435g

   

Case

• Cover:Off‐whitealuminum

• Front/rearpanel:Clearanodizedaluminum

• Optionalrackmountkitavailable‐RM4



Time Code Interfac

TCI 232

Rack mountable with an RM4
