Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



BroadbandSurgeArrestor

forDC‐3000MHzapplications

Helpprotectyourequipmentfromtheeffectsofligh tninginduced

surgeswiththebroadbandSA90‐SMASurgeArrestor.ThisDC‐passing

surgearrestoroperateswithfrequenciesupto3GHzandhelpswith

protectionfromlightningstrikes.Thearrestoriscompatiblewiththe

IEEE802.11bstandard.



FEATURES

• EasyinstallationforMasterclockGPSantenna systems‐compact

designfitsincrampedinstallations

• Weatherresistantinmatedcondition

• Qualityprotectionatacompetitiveprice 

• Goodreturnlosscharacteristics

• Lowthroughputenergyduringlightningstrikes

• Contains1eachsurgearrestorwithSMAfemaleandSMAmaleconnectorsanda18”(45cm)lowlosscoaxial

pigtail(SMAfemaletoSMAmale)everythingneededtoinstallthesurgearrestoreitheroutsideadjacentto

theantennaorinsideatthereceivinghardware.

• Formaximumprotection2unitscanbeinstalled‐seerearofsheetfordetails.



SPECIFICATIONS

Connectors:SMAFemale–SMAMale

PassBand:DC–3GHz

Maxpowerhandling:200W

Impedance:50Ω

Insertionloss,dB(MHz):Lessthan0.2dB(1000–3000)

VSWR:lessthan1.5:1,2.7GHz;1.65:13.0GHz

DCdischargevoltage:90VDC

Impulsedischargecurrent:5KA8/20μmaxwithstandingcurrent

Outer

conductorfinish:nickelplated

Hardwareprovided:Groundingscrew,washersandterminallug

Operatingtemperature:C.‐40°to+85°

10.2

SA90‐SMASurgeArrestor

(suppliedwithsurgearrestorand

SMAfemaletoSMAmalecable)

GPS

ntenna Surge Arresto

Model # SA90-SMA
